How To Draw a Piping & Instrumentation Diagram (P&ID)

Hoe to Draw a P&ID

Before reviewing how to draw a piping and instrumentation diagram (P&ID), let’s review a couple of key concepts.

A P&ID is an important engineering document that shows the interconnection of process equipment and instrumentation to control the design system. P&IDs provide the primary schematic drawing used for detailed engineering

Hoe to Draw a P&ID

P&ID Symbols

Creating a P&ID requires an in-depth understanding of the engineering design and the required symbols. P&ID symbols are a standard set of symbols used to represent components in a system.

The symbol used to draw a P&ID can vary by industry, project, and client. Typically, the engineering team will define a symbol library to be used on the project. Our comprehensive collection of common P&ID symbols is a good place to start studying engineering symbology.

How to Draw a Piping & Instrumentation Diagram

A piping and instrumentation diagram is drawn up at the design stage of a process to model the system.

It consists of a combination of the process flow datasheet, the mechanical equipment design, and the instrumentation engineering design.

Diagrams can range in complexity and either be hand-drawn or created using specialty software. Once the initial P&ID is complete, we like to use Bluebeam Revu for P&ID markups during online engineering squad checks.

Total Time Needed: 10 days

Tools Required

– A Computer
– Internet Connection
– Appropriate Software

Knowledge Required

– A degree in Process Engineering or Chemical Engineering
– An understanding of P&ID symbols

Here are 8 steps to draw your own P&ID

Step 1: Define the scope of the system
Before drawing a P&ID, you need to understand the overall process? What does it achieve?
Step 2: Identify the inputs
Are they manual or automatic? Where are the inputs coming from and leading to?
Step 3: Identify the outputs
What is the end product? What do you need to achieve it?
Step 4: List all the equipment in the process
Think about the instrumentation, control devices, piping and equipment.
Step 5: Define the relationship between components
How do they interact? Are they compatible?
Step 6: Piece together your flow
Start either at the beginning or end of the process and work through it methodically. What happens next in the system?
Step 7: Add detail
Add pipe, component, and instrumentation details such as measurements and sizes.
Step 8: Review the process
Look out for bottlenecks and inefficiencies.

How to Markup a P&ID Drawing with Valve Symbols in Real-Time

In this remote engineering collaboration demo video, Scott Mussbacher, Systems Integration Lead with Vista Projects, shows how to mark-up a P&ID drawing with valve symbols in real-time.
Watch Demo Video


What are piping & instrumentation diagrams (P&IDs)?

A piping and instrumentation diagram (P&ID) is a detailed engineering diagram indicating and depicting the relationship between piping, process equipment, instrumentation, and control devices. A P&ID is used to describe the overall engineering processes.

It shows the interconnection of process equipment and instrumentation to control the system, and provides the primary schematic drawing used for detailed engineering.

P&IDs can make up part of a process flow diagram (PFD), which indicates the general flow of a process and the relationship between major components and equipment.

In general, P&IDs are more detailed than PFDs, focusing on the instrumentation and measurements of devices.

How do I learn P&IDs?

P&ID diagrams are simple to pick up and read.

They commonly include mechanical equipment (i.e. pumps, compressors, heat exchangers, etc.), process piping sizes and identification, control instrumentation and designation (i.e. valves, vents, flanges, control inputs and outputs), interfaces for class changes, computer controlled systems and standardized components.

The piping information included on a P&ID is as follows:

– Pipe class and line numbers
– Flow direction
– Pipelines and flow lines
– Interconnection references
– Permanent start-up, flush and bypass lines
– Insulation and heat tracing
– Blinds and spectacle blinds

How to read P&IDs?

In order to read P&IDs you need familiarize yourself with standard symbols, common abbreviations and diagram basics.

To become familiar with standard symbols used for P&IDs and PFDs and gain access to a definitive guide click on the links respectively.

As well as standard symbols, common abbreviations are used in P&IDs. They are used to describe the function of a component.

Here’s a table of common abbreviations:

Basic Process Control System Abbreviations
AE Analyzer Element PV Control, Pressure Valve
BE Burner Element PCV Self Regulating Valve
DT Density Transmitter PG Pressure Gauge
EIV Emergency Isolation Valve PT Pressure Transmitter
FV Control Valve SC Local Speed Controller
FE Flow Element TV Control, Temperature Valve
FFC Flow Ratio Controller TG Temperature Gauge
GB Status Indication TE Temperature Element
HS Hand Switch VE Vibration Probe
HV Control, Hand Valve VS Vibration Switch
I DCS Logic Function VT Vibration Transmitter
IT Current Transmitter WT Weigh Scale Transmitter
JT Power Transmitter XV On/Off Valve
KS Time Switch XY Solenoid Valve
LG Level Gauge ZSC Positioned Closed Switch
LV Control, Level Gauge ZSO Position Opened Switch
MOV Motor Operated Valve
Instrumented Protective System/ Fire & Gas System Abbreviations
FZS Flow Safety Switch RV Pressure Relief, Safety Valve
FZT DP Safety XMTR TZS Temperature Safety Switch
HZS Hand Safety Switch TZT Temperature Safety Transmitter
IZ IPF Logic Safety Function XZV Shutdown Safety Valve
LZS Level Safety Switch XZY Hart Safety Positioner
LZT Level Safety Transmitter XZY Shutdown Safety Solenoid Valve
PDZT DP Safety Transmitter ZZSC Position Closed Safety Switch
PSE Safety Bursting Disk ZZSO Position Opened Safety Switch
PZS Pressure Safety SW ZZT Position Safety Transmitter
PZT Pressure Safety Transmitter
Power Supply Abbreviations
AS Air Supply HS Hydraulic Supply
IA Instrument Air NS Nitrogen Supply
PA Plant Air SS Stream Supply
ES Electrical Supply WS Water Supply
GS Gas Supply

The shape of the symbol may also provide vital information on the process.

For circular symbols, the dividing line suggests the type of mounting used for the device.

Continuous dividing line – the instrument is suitable for control room mounting.

Dotted dividing line – the instrument is suitable for technical room mounting.

No dividing line – the instrument is suitable for field application.

Control Signals for components show their input and output – e.g. electrical or hydraulic signals.

They are depicted by the lines entering and leaving the component – e.g. a dashed or wavy line.

The arrows between components also show the direction of flow in the system.

Once you’re familiar with the common symbols, abbreviations and diagram basics you can begin to understand the overall P&ID.

A typical method used to read a diagram is line tracing – following the line from the input to the output reading the components and measurements along the way.

You can grasp an understanding of the over system from all the processes within it.

What is a P&ID used for?

At the early stages of P&ID designs, the diagram provides a basis for the development of a system control scheme.

Through analysis and review – such as safety and operational investigation like hazard and operational studies – a system can be designed, determined and optimized to create an efficient system.

It’s critical to demonstrate the physical sequence of equipment and systems prior to installation to fully understand how they connect.

After installation, P&IDs play a significant role in the maintenance and modification of the process after the initial build.

Once changes have been made to the process, they are red-penned onto the diagram to keep track of changes and the current plant design.

P&IDs are vital in enabling the development of:

– Start-up sequences of the system
– Safety and regulatory requirements
– Control and shut down schemes
– Operational understanding of the system

What is the Best P&ID Software?

There are a number of pieces of software available to create and design P&IDs, ranging in complexity, intuitiveness and professionalism.

Here are some of the top 5 software currently available and their benefits and drawbacks:

Software Benefits Drawbacks
1. E-Draw Max – Easy to draw diagrams from scratch
– Plenty of template options
– Free online version
– Supports Windows, Mac, Linux and the Web
– The free online version contains watermarks on the diagrams
– Depending on use, licensing can be expensive
2. Lucid – Plenty of template options
– Accessible and easy to use
– No desktop app
– Subscription fee
3. Smart Draw – Similar interface to CAD
– Plenty of template options
– Free draw option available
– Complex to use
– Only available on Windows and the Web
– Depending on use can be expensive
4. Visual Paradigm – Supports most operating systems
– Plenty of template options
– Free to trial
– Complex software not suitable for beginners
5. PROCAD P&ID – Specialised CAD software for P&IDs
– Professional looking
– Library of standard symbols available
– Free to trial
– Tutorials available
– Available in both 2D and 3D
– Suitable for professionals
– No online version available and only supported by Windows

However, this is not a definitive guide, and there are a number of other software options for example AutoCAD.

In order to find the best software for your needs, have a look into the benefits and drawbacks as well as the overall functions of the software.

What does Process Flow mean?

Process flow is a term used to describe the general flow of plant process and the equipment used in chemical and process engineering, often depicted through a diagram.

A process flow diagram shows the relationship between major equipment used in a plant facility, omitting the minor details such as piping information and designations.

What is the difference between a P&ID and a PFD?

Both P&ID s and PFDs depict the relationship between components in a process.

A PFD outlines the general relationship between major components used to describe the overall process.

A P&ID is far more detailed – depicting a single process or loop – including further information of the components and measurements.

What is a Mechanical Flow Diagram?

A mechanical flow diagram is a flow diagram detailing the piping, flow rates and location of equipment in a process.

It’s used to identify errors in a system, for example, preventing the location of rotating equipment downstream from a hot tap.

This ultimately prevents damage to components in a system.

What is a Hookup Diagram?
Hookup diagrams are also referred to as installation drawings.

They detail the typical installation of a process or field instrument in the correct manner, so that once fitted, it can operate properly and prevent adverse issues affecting the measurements, such as liquid trapped in a gas impulse measuring device.

A hookup diagram details the accessory and tubing hook up for instruments, including standard specifications for the welding of hookup piping, pressure testing, painting requirements, heat tracing and installation.

Hookup diagrams include:

– Instrument tag number

– Number(s) of the loop drawing

– Elevations of components

– Layout, routing and isometric piping drawings

– Direction of slopes in the hookup lines

– Tagging of mechanical to instrumentation interface

– Tagging of all elements, fittings and valves

– Accessories, such as mono flanges and double blocks, etc.

– Material take off with part numbers, number of fittings, material type, size, connection, and mounting type

– Weather shield and tubing specifications

What is a GA drawing in piping?
GA drawings are general arrangement drawings that indicate the locations of major equipment in the plant.

They indicate the main piping items like valves and fittings.

Often the piping shown in the diagram is depicted using the top-view, and in the case of a pipe rack being present, sometimes the side-view.

GA drawings can also be developed for individual equipment. These drawings detail the main dimensions, a 2D view of the components from a top and side view (and sometimes a front view).

All nozzles are also detailed in individual drawings.


In general, P&IDs show the relationship between instruments, piping, and equipment to describe an overall process.

They vary in complexity and can take many different forms, ranging from hand drawn to software drawn.

To draw a P&ID, there are 8 simple steps to help depict the process, involving the inputs, outputs and components of the system.

Remember to familiarize yourself with abbreviations, component codes and diagram basics before you start.
